How to install and maintain a Butterfly Valve in Water Treatment System

Butterfly Valve in Water Treatment System

Butterfly Valves are essential for controlling or separating a system’s flow, and their proper installation is crucial to prevent future operational issues. These valves can be used in various applications such as water supply, wastewater treatment, slurry services, fuel handling systems, vacuum services, fire protection, power generation, compressed air, gas applications, chemical and oil industry, ships, and refineries. Proper installation is essential to avoid leaks and flow problems.

At Cair Euro Automation, we are the leading Valve Manufacturer offering the best quality Butterfly Valves and different types of industrial valves for maximum operation. Our experienced team of professionals helps our clients with extreme support to choose the right design and right valve for their essential needs and requirements of applications. This article aims to guide people about the installation and maintenance of Butterfly valves, Pre-installation guide, and troubleshooting installation problems.

Pre-installation Guidelines

Before Installing Butterfly Valves, it is essential to understand the valve’s working temperature and pressure rating. Specify the pressure at which it is meant to be used.

Valve seat location is not necessary for installation, but backflow prevention may be required for specific valve models. Disc clearance is important, as the ID of the tube and flanges should be large enough to allow the disc rim to slide into the opening freely.

Opening rotation allows the butterfly valve disc to revolve 360 degrees without endangering the valve or elastomer seat. The valve disc must be barely open but cannot expand past the valve liner face to minimize damage during installation. Valves with dead-end service functions are preferred.

Valve and flange preparation is crucial for preventing future issues. Remove debris, dirt, grit, dents, or surface imperfections on the valve seat or pipe flange to prevent flange sealing and outer leaks. Temporary line supports can be used to maintain parallel alignment or flange faces.

Necessary bolting is crucial for butterfly valve installation and following regulations guides. Careful planning and preparation are essential for proper installation and operation.

Operational conditions, such as temperature and pressure, should fall within the recommended range of the installed Butterfly Valve. The construction material of the valve should be chemically compatible with the medium used, and the valve’s flange ends and pipeline’s mating flanges should be clean and defect-free.

Installing Butterfly Valves at least six diameters away from upstream components and four pipe diameters away from downstream components ensures optimal performance by reducing turbulence and flow disturbances.

Step-by-Step Butterfly Valve Installation Guide

Before starting the installation process, it is crucial to review the manufacturer’s instructions carefully. The common steps in the installation are:

Positioning: The valve should be appropriately aligned with the pipe in which it will be fitted. Make sure the butterfly disc is open to prevent harm during installation.

Concentric Butterfly Valves: Also known as resilient-seated Butterfly valves, these valves include a rubber seat and disc centered in the middle. The installation technique includes positioning the valve between two pipe flanges and fastening it with bolts. After securing the valve, the disc can be rotated to ensure it doesn’t interfere with the valve seat or pipe flanges.

Double-offset Butterfly Valves: Installing a double offset butterfly valve requires precise alignment of the valve in the pipeline to guarantee that the disc may rotate freely without colliding with the pipe flanges. The offset design may need more precise placement and alignment than a concentric butterfly valve.

Triple Offset Butterfly Valve: installation of triple offset butterfly valves requires precision to ensure the offsets align correctly with the pipeline. This may necessitate more sophisticated mounting methods, which should be handled by skilled personnel.

Securing the Butterfly Valve: once the valve is positioned, it must be secured. This is commonly accomplished by fastening the valve to two pipe flanges. To minimize additional tension or deformation of the valve, tighten the bolts uniformly.

Lugged Butterfly Valve: Lugged Butterfly Valves have threaded sockets on both sides of the body, allowing them to be installed in a system using two bolt sets without the need for nuts. The valve is mounted between two flanges, each of which is secured by a pair of bolts. This design allows each side of the pipe system to be removed separately without impacting the other.

Wafer Butterfly Valve: Wafer Butterfly Valve The valve is placed by sliding it between the pipe’s flanges, which are then tightened to secure it in place. This makes them simple to install and disassemble, but they can’t be utilized when the flow has to be interrupted.

Connecting the Actuator: attach the handle (for manual valve) or gearbox to the valve. This is normally attached to the valve’s top and must be correctly positioned to function effectively.

Testing the Butterfly Valve: After installing the valve and connecting the actuator, it’s essential to test its operation.

Troubleshooting Common Installation Problems:

Misalignment: Ensure that the valve and pipe flanges are correctly aligned before securing the valve.

Difficulties in Securing the Valve: Difficulties in Securing the Valve If you’re having difficulties securing the valve, make sure the bolts are the right size and that the bolt holes on the valve and flanges line up properly. If the valve still cannot be fastened, there may be an issue with the valve or the flanges.

Issues with Testing the Valve’s Operation If the valve does not work smoothly during testing, it might be due to the disc catching within the valve or pipe, or the actuator being poorly attached or adjusted. Examine each of these sections and fix them as needed.

Butterfly Valve Maintenance Procedure

Regular maintenance is necessary to guarantee that the butterfly valve continues to work properly. This includes periodic checks, testing of the valve’s operation, and inspection for signs of wear or damage. Be alert for signs that the valve may not be alert for signs that the valve may not be working correctly. This can include leaks, unusual noises when the valve operates, or failure to open or close fully. If any of these indicators appear, the valve may need to be adjusted or repaired.

Verify that the valve functions correctly in both fully closed and fully opened positions. Adjust if necessary.

  • Visually inspect the valve and its surroundings to check for any signs of leakage. Check the gearbox regularly for symptoms of wear, corrosion, and damage.
  • Lubricate the gearbox often to decrease friction and wear. Inspect bolts, piping, wiring, and any other related equipment visually for issues that could interfere with operation, such as loosening or corrosion.
×
